| Battery Type |
LiFePO4 |
| Nominal Voltage |
51.2Vdc |
| Nominal Capacity (25°C, 0.2C) |
5KW |
10KW |
15KW |
| Adjustable Working Voltage |
40V - 58.4V |
| Max Continuous Discharge Current |
100A (-20°C ~ 40°C)
50A (40°C ~ 55°C) |
200A (-20°C ~ 40°C)
100A (40°C ~ 55°C) |
- |
| Max Pulse Discharge Current |
150A (1 sec configurable) |
300A (1 sec configurable) |
- |
| Max Continuous Charge Current |
100A (10°C ~ 30°C)
50A (30°C ~ 45°C) |
200A (10°C ~ 30°C)
100A (30°C ~ 45°C) |
- |
| Life Cycle (+25°C, 0.2C 80% DOD) |
>6000 Cycles |
| Cell Equalizer Current |
>70mA |
| Terminal |
M8 |
| Storage Duration |
6 Months at 25°C |
| Safety Standard |
IEC62619, UN38, MSDS |
| Maximum Parallel Connections |
16 pcs |
| Ingress Protection |
IP21 |
| Communication Function |
RS485 / CAN / RS232 (Standard), SNMP / WiFi / Bluetooth / Dry Contact (Optional) |
| Compatible With |
Pylon, Growatt, Voltronic, GoodWe, Luxpowertek, Sorotec, GINLONG, Schneider, SMA, Senerg, MUST, TBB, STUDER, WoW, DEYE, SVC |
| Protection |
Overcharge, Overdischarge, Overcurrent, Short Circuit, Over Temperature |
| Noise |
<40db (1 meter) |
| Working Temperature |
-20°C ~ +55°C (according to charge/discharge specs) |
| Humidity |
0-95% (No condensation) |
| Altitude |
<3000m |
| Dimensions (Product) |
L531 × W303 × H648.5 mm |
L630 × W303 × H883 mm |
L500 × W361 × H893 mm |
| Dimensions (Package) |
L561 × W346 × H828 mm |
L720 × W410 × H1060 mm |
L662 × W458 × H1048 mm |
| Net Weight |
54.5 kg |
97.5 kg |
132.6 kg |
| Gross Weight |
68.5 kg |
121 kg |
156.6 kg |
